Low Electromagnetic Interference 28mm Sensorless BLDC Motor
Features
- High Efficiency
- Handwound
- Low Current
- Low temperature
- Long Service Life
- Low Electromagnetic Interference
- All materials can normally work at high temperature
- Precision Ball Bearings For Smooth Operation
- Minimal Motor Maintenance Required
Specifications
Model | KV | Shaft /mm | Max A | Max W | Efficiency | Thrust/g | Propeller | ESC /A | weight/g | Li-Po | Diameter /mm | Length /mm |
ST2204C | 1450 | 3 | 6.9 | 50 | 76% | 150~350 | 9‘’ | 10A | 19 | 1~2 | 28mm | 13mm |
1650 | 8.4 | 62 | 78% | 200~400 | 8‘’ | |||||||
1750 | 9.5 | 70 | 78% | 300~420 | 7‘’/8 | |||||||
ST2206C | 1500 | 3 | 12 | 88 | 80% | 200-400 | 8‘’/9‘’ | 20A | 26 | 1~2 | 28mm | 23mm |
1900 | 16 | 118 | 80% | 400-600 | 8‘’ |
![]() |
