Motor Specifications (Can be Customized)
| 42mm*42mm*(59+L)mm |
| DC Input 12v,24v,36v,48v,60v (Can be Customized) |
| 12/25/50/75/100/125/200/250/300 to 800w (Can be Customized) |
| Variable speed from 1-3000rpm (Can be Customized) |
| 0.3/3/5/20/25/30 to 50N.m (Can be Customized) |
| shaft Dia: 8mm-D
shaft material: 40Cr /Carbon Steel /Stainless Steel
Shaft type: Bare /D-Cut /Double D-Cut /Pin Hole /Keyway shaft (Can
be Customized) |
| Ball bearing / Sleeve bearing |
| Wires, Connectors, Gearbox, Encoder, Brake, Cool Fan, etc
(Optional) |
Weight | According to gear stage(1090g to 1683g) |
Note | Motor specs such as voltage, speed, torque, shaft can be
customized. Please contact us if didn't find a suitable motor from
our specifications. |
Motor Details
1. INTEGRATED SHAFT
Better concentricity
High transmission efficiency
Never fall off
2. PLANETARY GEARBOX
Stronger torque than spur gear
Reduction ratio range from 1:3.3 to 1:3736
3. PLANETARY GEAR
Long service life
Plastic/POM/Steel gears are available
4. CUSTOMIZED SERVICE
Shaft, encoder and brake can be customized
Applications
FAQ
Q: How to select a suitable motor?
A:If you have motor pictures or drawings to show us, or you have
detailed specs like voltage, speed, torque, motor size, working
mode of the motor, needed lifetime and noise level etc, please do
not hesitate to let us know, then we can recommend suitable motor
per your request accordingly.
Q: Do you have a customized service for your standard motors?
A: Yes, we can customize per your request for the voltage, speed,
torque and shaft size/shape. If you need additional wires/cables
soldered on the terminal or need to add connectors, or capacitors
or EMC we can make it too.
Q: Do you have an individual design service for motors?
A: Yes, we would like to design motors individually for our
customers, but it may need some mould charge and design charge.
